Multi Pin Connector Lan Transformer With 10/100 Base-TX 24HSS1041-2 HF

  • 1
  • 2
  • 3

Place of Origin : Guangdong,China

Brand Name : LINK-PP

Certification : UL,RoHS,Reach,ISO

Model Number : 24HSS1041-2

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Packaging Details : T&R

Delivery Time : Stock

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Part Number : 24HSS1041-2 HF

Speed : 10/100 BASE-T

Number of Ports : SINGLE

Application : Lan Ethernet

Package : SMD

PIN number : 24

Temperature : -40℃ TO +85℃

Cores Per Port : 8

Contact Now

Detailed Information:

10/100 Base -T Magnetics Transformer Modules SMD, Rohs
LINK-PP Part Number LP5004ANL
Bothhand Part Number 24HSS1041-2 HF
Speed 10/100BASE-T
Number of Ports SINGLE
Application - LAN ETHERNET (NoPoE)
Package SMD
Temperature 0℃ TO +70℃
AutomDX YES
Comment SAME AS NL VERSION
Configuration RX T,C,S
Configuration TX T,C,S
Construction OPEN FRAME
Cores Per Port 8
Number of Ports SINGLE
Package Height (Inches) 0.260
Package Height (mm) 6.60
Package Length (Inches) 0.697
Package Length (mm) 17.7
Package Width (Inches) 0.496
Package Width (mm) 12.6
Turns Ratio RX 1CT:1CT
Turns Ratio TX 1CT:1CT



24HSS1041-2 HF Data Sheet

Multi Pin Connector Lan Transformer With 10/100 Base-TX 24HSS1041-2 HF

Key Features of 24HSS1041-2 HF Discrete LAN Magnetics

  • Designed for long-haul gigabit Ethernet 1000 BASE-T, full duplex applications.
  • Supports 4 pairs of Category 5 UTP cable.
  • Cable interface for isolation and low common-mode emissions.
  • Compliant with IEEE 802.3ab standard for 1000BASE-T.
  • Comply with ROHS & Halogen Free requirements.
  • Operating temperature range: 0℃ to +70℃.
  • Storage temperature range: -25℃ to +85℃.
