XFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NL

Product Categories
LINK-PP INT'L TECHNOLOGY CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

XFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NL

Brand Name : LINK-PP

Model Number : XFATM9-CTGA1-4M

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000/25K

Price : $0.05-$1.28

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 6000K/month

Delivery Time : Stock

Packaging Details : Tray Package: Carton size 32*30*31cm , G.W/carton 8.5kg , Qty/carton 1200pcs , SPQ 50pcs

Spec : XFATM9-CTGA1-4M

Port : 1x1 Female Rj45

Magnetics : 100 Base-T

LED : Green/Amber Leds

Mounting : Right Angle

Cross Ref : LPJ6014A175NL

File : PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters

Contact Now

XFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet RJ45 Magnetics Modules LPJ6014A175NL



Specification
item value
Model Number LPJ6014A175NL
Part Status Active
Connector Type RJ45
Applications 10/100 Base-T, AutoMDIX
Mounting Type Through Hole
Orientation 90℃ Angle (Right)
Termination Solder
Contact Finish Thickness 6.00u (0.152u)
LED Color Green/Amber
Number of Cores per Jack 4
Shielding Shielded, EMI Finger
Number of Ports Single Port
Features Board Guide
Tab Direction Up
Contact Finish Gold
Configuration RX/TX T,C
Turns Ratio RX/TX 1CT:1CT
Operating Temperature -40℃ ~ 85℃

XFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NL

XFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NL

Why Choose Us



XFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NLXFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NLXFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NLXFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NLXFATM9-CTGA1-4M 1x1 Port 100 Base-T Ethernet Rj45 Jack Module LPJ6014A175NL

FAQ
Q1: Can provide a sample test?
A: Yes,we are pleased to supply samples to test and check quality. free samples is also acceptable.

Q2:How about the MOQ?
A: NO MOQ , 1pcs OK . Small order welocome.

Q3: What’s the lead time?
A: Sample :1-3 days.Mass batch: 5-15 days .depend on the specific delivery time depends on the items and the quantity of your order. Please contact us for details.

Q4:Can make customized products ?
A:Yes, we can develop new mold at you need if you can provide us with the samples or drawings and specification.

Q5:What kind of payment do accept ?
A:ONLINE ( TRADE INSURANCE),,VISA,T/T,Western union,MoneyGram.
