LPJ16264CNL Cross 1-1840775-1 RJ45 Modular Jack 1PORT 100 BASE-T

Product Categories
LINK-PP INT'L TECHNOLOGY CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

LPJ16264CNL Cross 1-1840775-1 RJ45 Modular Jack 1PORT 100 BASE-T

Brand Name : LINK-PP

Model Number : 1-1840775-1

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000/25K

Price : $0.05-$1.28

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4200K-PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Part No : 1-1840775-1

Cross Part & datasheet : LPJ16264CNL

Applications : 10/100 Base-T, AutoMDIX

LED Color : Does Not Contain LED

Port : Single

Shielding : Shielded, EMI Finger

CategorFamilyy : Interconnects1000Base-TX

Operating Temperature : 0°C ~ 70°C

Contact Now

LPJ16264CNL Cross 1-1840775-1 RJ45 Modular Jack 1PORT 100 BASE-T
  • 1-1840775-1 Connector Telephone and Telecom
  • MagJack Integrated Connector Modules
  • Shielded with Filter Magnetic RJ45 Jack For Single Board Computers
  • High performance for maximum EMI suppression.
  • LAN interface suitable for 100Base-TX for Communication Controllers
  • Designed for network interface card application and Network Adapter
  • Original materials are RoHS and UL94-V0 compliant
  • ISO9001,SGS,UL,CE,REACH
  • Cross   LPJ16264CNL Jacks With Magnetics

1-1840775-1 CONN MAGJACK 1PORT 100 BASE-T  LPJ16264CNL Jacks With Magnetics
Type PCB Mount
Thru-Hole (THT)
Number of Ports
1, 2, and 4 Ports and Stackable 2x1, 2x2, 2x4, 2x6 and 2x8
Shield and Unshield
Available in Shield and Unshield
Connector Type
RJ45
PoE
Power Over Ethernet Integrated Or Without
Magnetics
Magnetic Integrated
Magnetics Speed
Magnetics 10/100Mbps Or 1000Mbps
Packaging
Tray Options
Tab Location
Tab Up and Tab Down Options
LED Color
Optional
Number of Positions
8 and 10 Positions or Others
Number of Contacts
8 and 10 Contacts or Others
RoHS Compliant
Yes
Solder Temperature
230 TO 240 degr.C 5-10 SECONDS
Solder High-Temp Option
260 degr.C 5-10 SECONDS
High Temperature Option
-40 to +85 Degrees F
Operating Temperature
-0 to 70 Degrees C

LPJ16264CNL Cross 1-1840775-1 RJ45 Modular Jack 1PORT 100 BASE-T



Applications:


Used for networking and communication equipments such as HUB, PC card, Switch, Router, PC Mainboard, SDH, PDH, IP Phone, xDSL modem

Competitive Advantage:
20 years production experience,
1100 staff,
100% test
Flexible delivery time
