LPJG19018CNL Cross 7498111001 SMT RJ45 Connector Built-in 10/100/1000Base-T

Name: LPJG19018CNL Cross 7498111001 SMT RJ45 Connector Builtin 101001000BaseT
Brand: LINK-PP
Price: 1 USD

Brand Name : LINK-PP

Model Number : 7498111001

Certification : ISO9001,SGS,UL,CE,REACH163

Place of Origin : GuangDong, China

MOQ : 200 PCS

Price : Supportive & Competitive

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3000000/Month

Delivery Time : Stock

Packaging Details : 50 pcs/tray,24tray /carton/32*30*31 , 9 KG/1200pcs/carton

PN : 7498111001

Made In China : SMJ-LPJG19018CNL

Application : 10/100/1000BT SMD

Ethernet : Fast Ethernet

Port : 1,2,4 Flexible

Hipot : 1500V

Contact Now

LPJG19018CNL Cross 7498111001 SMT RJ45 Connector Built-in 10/100/1000Base-T

7498111001 Jack

Trader Part Number

7498111001

Price Break	Unit Price	Extended Price
1-5	Free	Free
10-50	3.0	-
100-500	2.5	-
1,000-2,500	1.33	-
5,000	Dynamic	Dynamic
10,000	Dynamic	Dynamic
50,000	Negotiable	Negotiable
100,000	Negotiable	Negotiable
500,000	Negotiable	Negotiable

Made in China

SMJ-LPJG19018CNL

Manufacturer

LINK-PP China

Description

10/100/1000 SMD Rj45

Lead Free Status / RoHS Status

Lead free / RoHS Compliant

Quantity Available

2,000 PCS or 4 weeks

7498111001 Rj45 Electrical Specifications @25℃
Electrical Specifications @25℃
1.Turns Ratio(± 2%):
TX=1CT:1CT RX=1CT:1CT
2.OCL: 350uH Min
@100KHz,100mV,8mA bias current
3.Insertion Loss:
1-65MHz:-1.0dB Max
4.Return Loss(dB Min @100Ω± 15Ω):
1-10MHz:-20 30MHz:-16
60-80MHz:-12
5.Crosstalk(dB Min):
1-10MHz:-40 30-60MHz:-35
60-100MHz:-30
6.Common Mode Rejection(dB Min):
1-50MHz:-30 50-130MHz:-20
7.Isolation Voltage: 1500Vrms Min
8.Operating Temperature: -40℃～+85℃

LPJG19018CNL Cross 7498111001 SMT RJ45 Connector Built-in 10/100/1000Base-T
