HFJT1-LGHRPE-L12RL Rj45 Power Over Ethernet LPJK6070AHNL 10/100/1000 Mbps

Product Categories

LINK-PP INT'L TECHNOLOGY CO., LIMITED

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: HFJT1LGHRPEL12RL Rj45 Power Over Ethernet LPJK6070AHNL 101001000 Mbps
Brand: LINK-PP
Price: 0.05 USD

Brand Name : LINK-PP

Model Number : HFJT1-LGHRPE-L12RL

Certification : UL,ROHS,Reach,ISO

Place of Origin : China

MOQ : 50/500/1000/25K

Price : $0.05-$1.28

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 4200K-PCS/Month

Delivery Time : Stock

Packaging Details : 50pcs/tray,1200pcs/carton

Part Number : HFJT1-LGHRPE-L12RL

Equivalent : LPJK6070AHNL

I/O : 10/100/1000 Ethernet

Samples : Available

Contact Now

HFJT1-LGHRPE-L12RL = LPJK6070AHNL
Electrical Specifications @25℃ 1.Inductance: 350uH Min @ 100KHz,0.1V,8mA DC BIAS 2.Turns Ratio(±2%): 1CT∶1CT 3.Insertion Loss: 1-100MHz:-1.0dB Max 4.Return Loss(load 100Ω): 1-30MHz:-18dB Min 30-60MHz:-16dB Min 60-80MHz:-12dB Min 80-100MHz:-10dB Min 5.Crosstalk: 1-100MHz:-30dB Min 6.Common Mode Rejection: 1-100MHz:-30dB Min 7.Hipot:1500Vrms Min @60Hz 8.Operating Temperature: -40℃～+85℃.

Product Tags:

rj-45 ethernet jack
