XRJG-01J-1-H66-110 RJ45 With Integrated Magnetics Gigabit LPJG0813GDNL TV Box

Product Categories
LINK-PP INT'L TECHNOLOGY CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

XRJG-01J-1-H66-110 RJ45 With Integrated Magnetics Gigabit LPJG0813GDNL TV Box

Brand Name : LINK-PP

Model Number : XRJG-01J-1-H66-110

Certification : UL,ROHS,Reach,ISO

Place of Origin : GuangDong, China

MOQ : 50/500/1000

Price : 0.5~10 USD/PCS

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3000000/Month

Delivery Time : Stock

Packaging Details : package:60 pcs in 1 tray,22 tray in 1 carton, which is 37*30*30 cm, 10 KGS (1320 pcs) of each carton

part Number : XRJG-01J-1-H66-110

Specification : LPJG0813GDNL

Cross&Datasheet : LPJG0813GDNL

Apllication : 10/100 or 1000Base-T(x)

Original Munafactuer : LINK-PP

Mail Customer : Ti, Intel, Cisco, Samsung, Fluke, Arduino ,Hp,Jabil,Flextronics

Contact Now





XRJG-01J-1-H66-110 RJ45 With Integrated Magnetics Gigabit LPJG0813GDNL TV Box



Competitor Cross Reference





Part Number

Manufacturer

Part Number

 Manufacturer Description

XRJG-01J-1-H66-110

LPJG0813GDNL

 LINK-PP

XRJG-01J-1-H66-110    RJ45 With Integrated Magnetics Gigabit LPJG0813GDNL TV Box
Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Female Rj45

10/100

or 1000 Mbps

 Thru-Hole(SMT for Single Port)
Orientation Termination LED Color Shielding

90° Angle (Right) or

180°(Vertical)

 Solder Optional (Un)Shielded,EMI-Finger(With Or Wi)



Features

  • RJ-45 connector integrated with Filter
  • Size same as RJ-45 connector to save PCB board space
  • Reduce EMI radiation, Improve EMI performance
  • High performance for maximum EMI suppression.
  • ISO9001,SGS,UL,CE,REACH
  • Embedded mini PCI express Cellular modemfrom SierraWireless
  • Reduce EMI radiation, Improve EMI performance
  • Certified on all major carrier networks,attractive for network interface cards(NICS)Single port,
  • Multi-port and Stackable configurations (Thru-hole/ SMT)

  • Reduces the number of components to be placed on the board

  • Frees up board space and offers signal protection

  • Noise reduction in the system

  • Improved reliability and optimal system performance

  • Benefits of having shorter signal paths and the reliability gains from systems containing fewer components

  • Helps manufacturers reach their goals of cost reduction

Related Part

TG08-1505NZRL 43223-8019 XFATM9P-COMBO4-2S 13F-09C
TG23-1505NZRL 43223-8022 XFATM9Q-STACK12-4TF 13F-10C
TG24-1505NZRL 43223-8025 XFATM9Q-STACK8-4TF 11F-03L
TG26-1505NZRL 43223-8028 XFATM9QTVS-STACK12-4TF 11F-04
TG27-S004NZRL 43223-8031 XFATM9S-COMBO4-4S 13F-01D
TG28-1505NZRL 43223-8034 XF0656A-CTRG1-4M 13F-01D
TG37-S002NZRL 43223-8040 XF0656B-CLxu1-4MS 11F-B)-05
TG38-1505NZRL 43223-8041 XF10B11F-CAGY1-2MS 11F-B)-06
TG42-1505NZRL 43223-8042 XF10BASEA-CLxu1-4MS 11F-B)-07
TG63-1505NZRL 43223-8101 XF10BASEC-CAGY1-2MS 11F-B)-08
TG63-S002NZRL 43223-8104 XF6612D-CAGG1-4MS 11F-B)-10
TG73-1505NZRL 43223-8107 XF973G-CTGY1-4M 11F-B)-11
TG74-1505NZRL 43223-8110 XFATM11-CLxu1-4MS 11F-B)-12
TG80-1505NZRL 43223-8113 XFATM11A-CAxu1-4MS 11F-B)-14
TG91-1505NZRL 43223-8119 XFATM11B-CAxu1-4MS 11F-B)-16
TG05-1205NXRL 43223-8122 XFATM11D-CAxu1-4MS 11F-B)-17
TG28-1205NXRL 43223-8128 XFATM11E-CLxu1-4MS 11F-B)-17A
TG29-1205NXRL 43223-8131 XFATM11F-CLGG1-4MS 11F-B)-17B
TG39-1205NXRL 43223-8140 XFATM11F-CLxu1-4MS 11F-B)-18
TGSP-S024NXRL 43223-8146 XFATM11J-CAGY1-4MS 11F-B)-19
TG23-1505NXRL 43223-8149 XFATM11N-CAxu1-2MS 11F-B)-19A





XRJG-01J-1-H66-110 RJ45 With Integrated Magnetics Gigabit LPJG0813GDNL TV Box

XRJG-01J-1-H66-110 RJ45 With Integrated Magnetics Gigabit LPJG0813GDNL TV Box



Why Choose LINK-PP







Quality



World’s Leader supplier of Integrated RJ45 Connector and Discrete Magnetic Transformers.

Original materials suppliers are selected and appointed by Tyco Electronic ,and then put into production at the standard of Tyco Electronic .



  • Manufactured under strict controls.
  • ISO 9001:2008
  • UL Certification
  • Reach Cetitifaction
  • RoHS compliance
  • OEM Of TE(Tyco) For 9 Years
  • Active Environmental policy
  • Every module tested (not just batch tested)
Main Customers




Texas Instruments INTEL SAMSUNG FLUKE EKF HUAWEI IBM CISCO
FLEXTRONICS JABIL Foxconn CANON Arduino  -- --- ---





LINK-PP RJ45  Designed for BeagleBone Black of Texas Instruments



LINK-PP is the preferred supplier of Texas Instruments ,Samsung, Cisco ,Siemens and INTEL.

Welcome to visit the Texas Instruments's websit: http://www.ti.com/tool/beaglebk#0 You will look at our logo "LINK-PP”on  BeagleBone Board



                                LINK-PP ------------ Appointed Supplier And Supporter Of Embedded System for Ti
